Name: 1220x2440x18mm Concrete Formwork System Plywood
Brand: Xingang
SKU: 184803520

Any interest pls contact Ailsa,mobile: 008618953984274(WhatsApp&Wechat).

Product Description

Product Name	H20 beam H20 wooden beam formwork H20 timber team
Flange	Finland Spruce
Web	Birch or Poplar or Pine plywood
Flange size	80mm40mmlength up to 6 meter
Web size	27mm150mmlength up to 6meter
Weight	4.8kg per running meter
Glue	WBP exterior used weather & waterproof
Technical data	Bending moment-max:5kN/m;Shear force-min:11.0kN; Bending-max:1/500;Live load (Bending stiffness):1.5kN/m2
Loading Quantity	52cbm - 58cbm per 40'hq, 45cbm per 40'ft, 22.5cbm per 20'ft
End finish	plastic or steel protector,waterproof
Surface finish	yellow painting,waterproof
Lead Time	15 days after receiving your prepayment or L/C
MOQ	1X20'ft Container
Productivity	15000cbm per month
Packing	pallets packing,suitable for container loading and unloading
Payment terms	TT or L/C at sight
Usage	For construction use: slab formwork system,vertical formwork(wall,column,hydraulic climbing etc.),adjustable arced formwork etc,Carry film faced plywood
